Specifications
Maximum test force: 1000KN;
Accuracy level: level 1;
Relative error of indication: ±1%;
Effective measurement range: 1%-100%F·S (full scale is not divided);
Deformation measurement range: 1%-100%F·S;
Relative error of deformation indication: ±1%;
Relative error of displacement indication: ±1%;
Displacement measurement resolution: 0.001mm;
Maximum speed of piston rise: 150 mm/min;
The maximum speed of the piston drop is 100 mm/min;
Maximum compression space: 500 mm;
Maximum stretching distance: 700 mm;
Effective distance between two columns: 660 mm × 400 mm;
Piston stroke: 700 mm;
Round sample clamping diameter: Φ14 mm -Φ45 mm;
Flat specimen clamping thickness: 0 mm -40 mm;
Upper and lower platen size: Φ250 mm;
Mainframe dimensions: 980 mm × 720 mm × 3210 mm;
Oil source cabinet size: 860 mm × 640 mm × 1680 mm;
Machine power: 4kW;
Oil source cabinet weight: 300 kg;
Host weight: about 4000 kg;

SSB-1000DL electro-hydraulic servo universal testing machine (single space) is a high-precision material testing equipment that uses hydraulic power source drive, electro-hydraulic servo control technology, computer data acquisition and processing, and can realize closed-loop control and automatic detection. The main engine, oil source (hydraulic power source), measurement and control system, and test equipment are composed of four parts, and the maximum test force is 1000kN.

SSB-1000DL electro-hydraulic servo universal testing machine (single space) can meet the national standard test of metal tensile test regulations, and can also realize stretching, compression, shearing, etc. of different materials or products according to other standards. Type test, which can obtain the tensile strength, yield strength, specified non-proportional extension strength, elastic modulus and other performance indicators of the tested materials, can achieve equal rate loading, equal rate deformation, equal rate displacement, iso-rate strain, etc. Closed-loop control for process qualification verification of materials or products.
